Low Energy and Extra Low Pressure TW-4040 Membrane

designed for low-energy applicationsKey Features • TW-4040 delivers high-quality water at low pressure at harsh water conditions, using Hiton’s innovative, proprietary technology for low energy applications. • Industry-leading active area (100 sqft and 90sqft), which provides less fouling due to lower operating flux while still achieving higher flow. • Offers high salt rejection at low pressure in harsh water conditions.

PREV：Low Foulding and High Rejection Brackish Water USE BW-8040 Membrane NEXT：Household Membrane

Details

Model	Sheet area ft² (m²)	Pressure psi (MPa)	Flow GPD (m³/d)	Salt Rejection (%)
TW-4040-HR	90(8.4)	150(1.03)	2400(9.1)	99.3
TW-4040-HF	90(8.4)	150(1.03)	2700(10.2)	99
TW-4040-FR	90(8.4)	150(1.03)	1900(7.2)	99.5

a. The flow and rejection are based on the following testing conditions: 1500ppm softened tap water,

temperature 25°C、pH7.5-8、recovery rate 15% and above, testing pressure

b. One single membrane flow may fluctuate within±15%
